Construction Packages

Design & Drawings

Package Includes:

Detailed 2D floor plans will be provided.
Note: This Floor plan is just for reference only, Floor plan for each project will be designed as per client’s requirements.
3D elevation view will be provided.
Note: This elevation image is just for reference only, Elevation for each project will be designed as per client’s taste and requirement.
Structural Drawings:
Detailed Plinth Beam layouts, Slab shuttering and reinforcements, Columns, Footings and Centre line Drawings, and working drawings will be provided.

Sample Design

Structure & Civil

Steel:
ISI standard FE-500 TMT Steel will be used.
IndiaGold or equivalent brands will be used.
Steel Rods starting from 6mm upto 20mm will be used according to the structural design and requirement.
Cement:
ISI Standard 53 and 43 Grade cement will be used.
53 Grade will be used for Masonry and 43 Grade will be used for Plastering.
MAHA/Priya/KCP or equivalent Brands will be used.
sand - M-Sand will used for Masonry and Plastering M-Sand will be used for Plastering.

Blocks/Bricks:
Solid 6-inch and 4-inch concrete blocks will be used.
6-inch blocks for External walls and 4-inch blocks for internal walls.
Note - Red-bricks can be used with Extra cost of Rs.80/sqft and Wire-cut bricks for Rs.100/sqft on the package.
Concrete: ISI Standard M25/M20 Grade Ready Mix Concrete will used for Footing and Slab.
Aggregates - 20mm and 40mm will used.
Waterproofing - Dr.Fixit Water proofing solution will be used.

Kitchen

Kitchen Granite Platform:
Cost of the Granite platform will be upto Rs.100/sqft.
Thickness of the Granite will be 40mm.
Ceramic Wall Tiles:
Ceramic Wall tiles worth upto Rs.35/sqft will be provided.
Height of the Wall tiles will be up to 2 feet above the Granite platform.

Kitchen Sink, Faucets and Accessories:
Stainless Steel Single Bowl sink of worth upto Rs.3000 will be provided.
Sink Faucet and Accessories worth upto Rs.1000 will be provided.

Bathroom

Sanitaryware and CP fittings:
Sanitaryware and CP fittings will be used of worth upto Rs.20,000.
Includes EWC, Washbasin with Pillarcock, Wallmixer/Diverter, Health Faucet, Overhead shower with Arm, Concealed stopcock, CP fittings and Accessories.

Ceramic Wall and Floor Tiles:
Ceramic Wall tiles worth upto Rs.35/sqft and Floor tiles worth upto Rs.35/sqft will be provided.
Height of the Wall tiles will be upto 7 feet above the Floor.
Anti-Skid Ceramic Floor tiles will be provided.
CPVC/PVC: Astral brand CPVC and PVC will be used in Plumbing.
Bathroom Doors: PVC Door And PVC Frame.

Note: Bathrooms will be waterproofed to remain free of leaks. Warranty of 5 years will be provided for Water proofing.

Woodwork

Main door and Frame:
Main door and Frame will be made of Teak wood.
Height and width of the Main door frame will be 7 feet X 3 feet 6 inches.
Thickness of the wood section will be 5 inches X 3 inches.

Door designs will be as per company standards.
Windows:
Standard 2-track Aluminum sliding windows with Clear glass & 10mm MS grills will be provided.
Height and Width of the Windows and Grill design will be as per company standards.

Internal Doors and Frames:
SAL wood will be provided for Internal Door Frames.
Primer coated Membrane Doors will be provided for Internal Rooms.
Height and width of the Main door frame will be 7 feet X 3 feet.
Thickness of the wood section will be 5 inches X 3 inches.
Door designs will be as per company standards.

Painting

Interior Painting:
2-coats of JK wall putty will be done.
2-coats of Asianpaints Tractor emulsion will be provided.

External Painting:
1-coat of Exterior Primer will be done.
2-coats of Asianpaints Ace Weatherproof paint will be provided.
Metal and Wood Painting: 2-coats of Asianpaints Enamel painting will be done for Window grills, MS Staircase railings, MS Main Gate.

Flooring

Living and Dining: Branded Vitrified tiles of worth upto Rs.50/sqft will be provided.
Bedroom: Branded Vitrified tiles of worth upto Rs.50/sqft will be provided.

Staircase: Anti-Skid tiles of worth upto Rs.50/sqft will be provided.
Balcony and Open areas: Anti-skid tiles of worth upto Rs.40/sqft will be provided.
Parking: Anti-skid Parking tiles of worth upto Rs.35/sqft will be provided.

Note: Balconies will be waterproofed to remain free of leaks. Warranty of 5 years will be provided for Water proofing.

Electrical

Wires: Anchor brand Fire-proof wires will be provided.
Switches and Boards: Anchor/ROMA Brand Switches and Panels will be provided.
Note: Electric fixing and fixtures like Fans, Bulbs, Motor, Meters, Meter Box etc., are not included in the package. It will be of additional cost.

Water Tanks

Overhead Tank:
ISI standard multi-layered Water Tank will be provided.
Water tank capacity starts from 1000 liters and the capacity depends on the total built-up area.
Underground Sump/Tank:
Underground Sump will be of 8” Solid concrete blocks with waterproof plastering
Sump tank capacity starts from 5000 liters and the capacity depends on the total built-up area.

Gates and Railings

Gates:
MS gates with Standard designs will be provided.
Designs will be as per company standards.
16-gauge round/box pipes will be used.
Staircase and Balcony Railings:
MS Railings with Standard designs will be provided.
Designs will be as per company standards.
16-gauge round/box pipes will be used.

Add-ons

Anti-Termite treatment - Anti-Termite treatment will be done.
Inverter provision - Inverter provision will be provided.

Compound wall and Parapet wall

Compound wall:
Standard Compound wall of height 4 feet will be provided.
4-inch Solid concrete blocks & both side plastering and painting will be done.
Parapet wall:
Standard Parapet wall of height 3 feet will be provided.
4-inch Solid concrete blocks & both side plastering and painting will be done.

Exclusions from the Package

Interiors:
Interiors are not included in the package
Temporary Power:
Client must provide Temporary power for the construction.
Temporary power renewal should be done by Client every month until the Construction of project is completed.
Water for Construction of the project: Required amount of Water for construction of the project should be provided by the Client.
Government approvals:
Getting Approvals from the Government is excluded from the package.
Client must get all the Government approvals for the project.

Electrical/BESCOM:
Electrical Meters and Meter Box are not included in the package.
BESCOM charges are NOT included in the package.
Road cutting:
Road cutting chares for BESCOM and BWSSB are NOT included in the package.
Breaking/drilling Rock:
Rock breaking or drilling expenses will be borne by Client.

Builhood Pricing

Main areas: Living, Kitchen, Bedrooms, Bathrooms and Staircase will be charged at Rs.1465/sqft.
Parking and Open areas:
Parking area will be charged at 75% of Rs.1465/sqft.
Utility, Balcony and common areas will be charge at 75% of Rs.1465/sqft.
Other areas : Headroom and Tank room will be charged at 85% of Rs.1465/sqft.
Note:Standard height of Headroom is 8-foot and Tank room is 6-foot.

Note: GST [CGST + SGST] is 18% [9% + 9%]

Incl GST* indicates the following...

• CGST 9% will be borne by Company.

• SGST 9% shall be borne by Customer.

Warranty

Warranty of 5 years will be provided for the Construction.
Warranty starts from the date of Handing over the Project to the Client.
Warranty for all the Products can be availed directly from the Manufacturer of the product.
We will be providing all the required Bills of products to the client to claim warranty.

Note

Civil Engineer will be assigned for the project for inspection and monitoring the quality of work and progress.
Sheds would be constructed at site premises for material storage and Watchman/Labor.
Soil Testing would be done by us before starting the construction.
All the Brand's logos and Some product's images are mentioned just for understanding/reference purpose only. Actual product may look different from the images mentioned in this package.
Floor plans and 3D elevations mentioned in this document is just for reference purpose only, the designs will change as per Site dimensions, Client's requirements etc.
Looking forward to serving you the Quality and Professional Construction service.

Design & Drawings

Package Includes:

Floor Plans: Detailed 2D floor plans will be provided.
Note: This Floor plan is just for reference only, Floor plan for each project will be designed as per client’s requirements.
 3D elevation view will be provided.
Note: This elevation image is just for reference only, Elevation for each project will be designed as per client’s taste and requirement.
Structural Drawings:
Detailed Plinth Beam layouts, Slab shuttering and reinforcements, Columns, Footings, Centre line Drawings and working drawings will be provided.

Sample Design

Structure & Civil

Steel:
ISI standard FE-500/550 TMT Steel will be used.
PrimeGold, Meenakshi or equivalent Brands will be used.
Steel Rods starting from 6mm upto 20mm will be used according to the structural design and requirement.
Cement:
ISI Standard 53 and 43 Grade cement will be used.
Ramco, Zuari or equivalent Brands will be used.
53 Grade will be used for Masonry and 43 Grade will be used for Plastering.
Sand -
Water washed M-Sand will be used.
Water washed M-Sand will be used for Masonry and Plastering-Sand will be used for Plastering.

Blocks/Bricks:
Solid 6-inch and 4-inch concrete blocks will be used.
6-inch blocks for External walls and 4-inch blocks for internal walls.
Note - Wire-cut Red-bricks can be used with Extra cost of Rs.100/sqft on the package.
Concrete: ISI Standard M25 Grade Ready Mix Concrete will used for Footing and Slab.
Aggregates - 20mm and 40mm will used.
Waterproofing - Dr.Fixit Water proofing solution will be used.

Kitchen

Kitchen Granite Platform:
Cost of the Granite platform will be upto Rs.130/sqft.
Thickness of the Granite will be 40mm.
Ceramic Wall Tiles:
Ceramic Wall Tiles worth upto Rs.45/sqft will be provided.
Height of the Wall tiles will be upto 2 feet above the Granite platform.

Kitchen Sink, Faucets and Accessories:
Stainless Steel Single Bowl sink of worth upto Rs.4500 will be provided.
Sink Faucet and Accessories worth upto Rs.1500 will be provided.

Bathroom

Sanitaryware and CP fittings:
Sanitary ware and CP fittings will be used of worth up to Rs.30,000 per Bathroom.
Includes EWC, Washbasin with Pillar cock, Wall mixer/Diverter, Health Faucet, Overhead shower with Arm, Concealed stopcock, CP fittings and Accessories.

Ceramic Wall and Floor Tiles:
Ceramic Wall tiles worth upto Rs.45/sqft and Floor tiles worth upto Rs.45/sqft will be provided.
Height of the Wall tiles will be upto 7 feet above the Floor.
Anti-Skid Ceramic Floor tiles will be provided.
CPVC/PVC: Ashirwad/Supreme brand CPVC and PVC will be used in Plumbing.
Bathroom Doors: Flush Water-Proof Doors will be provided.

Note: Bathrooms will be waterproofed to remain free of leaks. Warranty of 5 years will be provided for Water proofing.

Woodwork

Main door and Frame:
Main door and Frame will be made of indian Teak wood.
Height and width of the Main door frame will be 7 feet X 3 feet 6 inches.
Thickness of the wood section will be 5 inches X 3 inches.
Door designs will be as per company standards.
Windows:
Standard Aluminum 3-track sliding windows with clear glass & 10mm MS grills will be provided.
Height and Width of the Windows and Grill design will be as per company standards.

Internal Doors and Frames:
SAL wood will be provided for Internal Door Frames.
Solid Membrane Doors will be provided for Internal Rooms.
Height and width of the Main door frame will be 7 feet X 3 feet.
Thickness of the wood section will be 5 inches X 3 inches.
Door designs will be as per company standards.

Painting

Interior Painting:
2-coats of Birla wall putty will be done.
2-coats of Asianpaints Premium emulsion will be provided.

External Painting:
1-coat of Asianpaints Exterior Primer will be done.
2-coats of Asianpaints APEX Weatherproof paint will be provided for elevation and ACE for other sides.
Metal and Wood Painting:
2-coats of Asianpaints Enamel painting will be done for Window grills, MS Staircase railings, MS Main Gate.
Same will be applied for Window Frames and Shutters in case of Wooden Windows.

Flooring

Living and Dining: Branded Vitrified tiles of worth upto Rs.70/sqft will be provided.
Bedroom: Branded Vitrified tiles of worth upto Rs.70/sqft will be provided.

Staircase: Sadarahalli granite of worth upto Rs.60/sqft will be provided.
Balcony and Open areas: Anti-skid tiles of worth upto Rs.45/sqft will be provided.
Parking: Anti-skid Parking tiles of worth upto Rs.45/sqft will be provided.

Note: Balconies will be waterproofed to remain free of leaks. Warranty of 5 years will be provided for Water proofing.

Electrical

Wires: V-Guard or equivalent brand Fire-proof wires will be provided.
Switches and Boards: GM or equivalent Brand Switches and Panel boards will be provided.
Note: Electric fixing and fixtures like Fans, Bulbs, Motor, Meters, Meter Box etc., are not included in the package. It will be of additional cost.

Overhead Tank

ISI standard multi-layered Water Tank will be provided.
Water tank capacity starts from 1000 liters and the capacity depends on the total built-up area.
Underground Sump/Tank:
Underground Sump will be of 8” Solid concrete blocks with waterproof plastering.
Sump tank capacity starts from 5000 liters and the capacity depends on the total built-up area.

Gates and Railings

Gates:
MS gates with Standard designs will be provided.
Designs will be as per company standards.
16-gauge round/box pipes will be used.
Staircase and Balcony Railings:
MS Railings with Standard designs will be provided.
Designs will be as per company standards.
16-gauge round/box pipes will be used.

Add-ons

Anti-Termite treatment - Anti-Termite treatment will be done.
Solar provision - Solar provision will be provided.
CCTV provision - CCTV Provision for 2-points will be provided.
Inverter provision - Inverter Provision will be provided.

Compound wall and Parapet wall

Compound wall:
Standard Compound wall of height 4 feet will be provided.
4-inch Solid concrete blocks will be used.
Parapet wall:
Standard Parapet wall of height 3 feet will be provided.
4-inch Solid concrete blocks will be used.

Exclusions from the Package

Interiors -
Interiors are not included in the package.
Temporary Power -
Client must provide Temporary power for the construction.
Temporary power renewal should be done by Client every month until the Construction of project is completed.
Water for Construction of the project -
Required amount of Water for construction of the project should be provided by the Client.
Government approvals -
Getting Approvals from the Government is excluded from the package.
Client must get all the Government approvals for the project.

Electrical/BESCOM -
Electrical Meters and Meter Box are not included in the package.
BESCOM charges are NOT included in the package.
Road cutting - Road cutting chares for BESCOM and BWSSB are NOT included in the package.
Breaking/drilling Rock - Rock breaking or drilling expenses will borne by Client.

Builhood Pricing

Main areas: Living, Kitchen, Bedrooms, Bathrooms and Staircase will be charged at Rs.1610/sqft.
Parking and Open areas:
Parking area will be charged at 75% of Rs.1610/sqft.
Utility, Balcony and common areas will be charge at 75% of Rs.1610/sqft.
Other areas : Headroom and Tank room will be charged at 85% of Rs.1610/sqft.
Note: Standard height of Headroom is 8-foot and Tank room is 6-foot.

Note: GST [CGST + SGST] is 18% [9% + 9%]

Incl GST* indicates the following...

• CGST 9% will be borne by Company.

• SGST 9% shall be borne by Customer.

Warranty

Warranty of 5 years will be provided for the Construction.
Warranty starts from the date of Handing over the Project to the Client.
Warranty for all the Products can be availed directly from the Manufacturer of the product.
We will be providing all the required Bills of products to the client to claim warranty.

Note

Civil Engineer will be assigned for the project for inspection and monitoring the quality of work and progress.
Sheds would be constructed at site premises for material storage and Watchman/Labor.
Soil Testing would be done by us before starting the construction.
All the Brand's logos and Some product's images are mentioned just for understanding/reference purpose only. Actual product may look different from the images mentioned in this package.
Floor plans and 3D elevations mentioned in this document is just for reference purpose only, the designs will change as per Site dimensions, Client's requirements etc.
Looking forward to serving you the Quality and Professional Construction service.

Design & Drawings

Package Includes:

Floor Plans: Detailed 2D floor plans will be provided
Note: This Floor plan is just for reference only, Floor plan for each project will be designed as per client’s requirements.
3D elevation view will be provided
Note: This elevation image is just for reference only, Elevation for each project will be designed as per client’s taste and requirement.
Structural Design:
Detailed Plinth Beam layouts, Slab shuttering and reinforcements, Columns, Footings, Centre line Drawings and working drawings will be provided
Plumbing & Electrical Drawings:
Detailed Plumbing and Electrical drawings will be provided.

Sample Design

Structure & Civil

Steel:
ISI standard FE-500 TMT Steel will be used.
Jindal/Indus or equivalent Brands will be used.
Steel Rods starting from 6mm upto 20mm will be used according to the structural design and requirement.
Cement:
ISI Standard 53 and 43 Grade cement will be used.
ACC/Birla/Ultratech or equivalent brands will be used
53 Grade will be used for Masonry and 43 Grade will be used for Plastering.
sand -
Certified water-washed M-sand will be provided.
M-Sand will used for Masonry and Plastering-Sand will be used for Plastering.

Blocks/Bricks:
Solid 6-inch and 4-inch concrete blocks will be used.
6-inch blocks for External walls and 4-inch blocks for internal walls.
Note - Wire cut Red-bricks can be used with Extra cost of Rs.100/sqft on the package.
Concrete: ISI Standard M25 Grade Ready Mix Concrete will used for Footing and Slab.
Aggregates - 20mm and 40mm will used.
Waterproofing - Dr.Fixit/FOSROC Water proofing solution will be used.

Kitchen

Kitchen Granite Platform:
Cost of the Granite platform will be up to Rs.160/sqft.
Thickness of the Granite will be up to 40mm.
Granite skirting of 4-inch will be provided on the platform.
Ceramic Wall Tiles:
Ceramic Wall Tiles worth upto Rs.55/sqft will be provided.
Height of the Wall tiles will be upto 2 feet above the Granite platform.

Kitchen Sink, Faucets and Accessories:
Stainless Steel (or) Quartz of worth up to Rs.6000 will be provided.
Sink Faucet and Accessories worth up to Rs.2000 will be provided.

Bathroom

Sanitaryware and CP fittings:
Sanitaryware and CP fittings will be used of worth upto Rs.40,000.
Includes EWC, Washbasin with Pillar cock, Wall mixer/Diverter, Health Faucet, Overhead shower with Arm, Concealed stopcock, CP fittings and Accessories.

Ceramic Wall and Floor Tiles:
Ceramic Wall tiles worth upto Rs.55/sqft and Floor tiles worth upto Rs.55/sqft will be provided.
Height of the Wall tiles will be upto 7 feet above the Floor.
Anti-Skid Ceramic Floor tiles will be provided.
CPVC/PVC: Ashirwad/Supreme brand CPVC and PVC will be used in Plumbing.
Bathroom Doors: WPVC Water-Proof Doors will be provided.

Note: Bathrooms will be waterproofed to remain free of leaks. Warranty of 5 years will be provided for Water proofing.

Woodwork

Main door and Frame:
Main door and Frame will be made of Premium Teak wood.
Height and width of the Main door frame will be 7 feet X 3 feet 6 inches.
Thickness of the wood section will be 5 inches X 3 inches.
Door designs will be as per company standards.
Internal Doors and Frames:
Honne wood will be provided for Internal Door Frames.
Laminated Doors will be provided for Internal Rooms.
Height and width of the Main door frame will be 7 feet X 3 feet.
Thickness of the wood section will be 5 inches X 3 inches.
Door designs will be as per company standards.

Windows:
Standard UPVC 3-track sliding windows with clear glass & 11mm MS grills will be provided.
Height and Width of the Windows and Grill design will be as per company standards.

Painting

Interior Painting:
2-coats of Birla wall putty will be done.
1-coat of Interior Primer will be provided.
2-coats of Asianpaints Premium emulsion will be provided.

Exterior Painting:
1-coat of Asianpaints Exterior Primer will be done.
2-coats of Asianpaints APEX or equivalent Weatherproof paint will be provided.
Metal and Wood Painting:
2-coats of Asianpaints Enamel painting will be done for Window grills, MS Main Gate.
Same will be applied for Internal Window Frames.

Flooring

Living and Dining: Granite flooring/ Branded Vitrified tile flooring of worth upto Rs.100/sqft will be provided.
Bedroom: Granite flooring/ Branded Vitrified tile flooring of worth upto Rs.90/sqft will be provided.
Staircase:
Granite of worth upto Rs.75/sqft will be provided for staircase steps.
4-inch Skirting with chamfering will be provided.

Balcony and Open areas: Anti-skid tiles of worth up to Rs.60/sqft will be provided.
Parking: Anti-skid Parking tiles of worth upto Rs.55/sqft will be provided.
Elevation Cladding:
Front Elevation Cladding will be provided.
Cost of cladding will be upto Rs.60/sqft.
Cladding area will be upto 5% of the total built-up area.

Note: Balconies will be waterproofed to remain free of leaks. Warranty of 5 years will be provided for Water proofing.

Electrical

Wires: Finolex or equivalent brand Fire-proof wires will be provided.
Switches and Boards: Goldmedal or equivalent Switches and Panel boards will be provided.
Note: Electric fixing and fixtures like Fans, Bulbs, Motor, Meters, Meter Box etc., are not included in the package. It will be of additional cost.

Overhead Tank

ISI standard multi-layered Water Tank will be provided.
Water tank capacity starts from 1000 liters and the capacity depends on the total built-up area.
Underground Sump/Tank:
Underground Sump will be of 8” Solid concrete blocks with waterproof plastering.
Sump tank capacity starts from 5000 liters and the capacity depends on the total built-up area.

Gate and Railings

Main Gate:
MS gates with Modern designs will be provided.
16-gauge round/box pipes will be used.
Staircase and Balcony Railings:
304 grade Stainless Steel Railings will be provided.
Designs will be as per company standards.
Sample images for SS Railings:

Compound wall and Parapet wall

Compound wall:
Standard Compound wall of height 4 feet will be provided.
4-inch Solid concrete blocks & both side plastering and painting will be done.

Addons

Parapet wall:
Standard Parapet wall of height 3 feet will be provided.
4-inch Solid concrete blocks & both side plastering and painting will be done.
Anti-Termite treatment - Anti-Termite treatment will be done.
Solar provision - Solar provision for all the Bathrooms and Kitchens will be provided.
CCTV provision - CCTV Provision for 3-points will be provided.
Inverter provision - Inverter Provision will be provided.
Texture Painting - Texture painting for Front Elevation will be provided (As per Company Standards).
Elevation Cladding - Elevation cladding will be provided as mentioned in the Flooring section.

Exclusions from the Package

Interiors - Interiors are not included in the package.
Temporary Power -
Client must provide Temporary power for the construction.
Temporary power renewal should be done by Client every month until the Construction of project is completed.
Water for Construction of the project - Required amount of Water for construction of the project should be provided by the Client.
Government approvals -
Getting Approvals from the Government is excluded from the package.
Client must get all the Government approvals for the project.

Electrical/BESCOM -
Electrical Meters and Meter Box are not included in the package.
BESCOM charges are NOT included in the package.
Road cutting - Road cutting chares for BESCOM and BWSSB are NOT included in the package.
Breaking/drilling Rock - Rock breaking or drilling expenses will born by Client.

Builhood Pricing

Main areas: Living, Kitchen, Bedrooms, Bathrooms and Staircase will be charged at Rs.1740/sqft.
Parking and Open areas:
Parking area will be charged at 75% of Rs.1740/sqft.
Utility, Balcony and common areas will be charge at 75% of Rs.1740/sqft.
Other areas : Headroom and Tank room will be charged at 85% of Rs.1740/sqft.
Note : Standard height of Headroom is 8-foot and Tank room is 6-foot.

Note: GST [CGST + SGST] is 18% [9% + 9%]

Incl GST* indicates the following...

• CGST 9% will be borne by Company.

• SGST 9% shall be borne by Customer.

Warranty

Warranty of 5 years will be provided for the Construction.
Warranty starts from the date of Handing over the Project to the Client.
Warranty for all the Products can be availed directly from the Manufacturer of the product.
We will be providing all the required Bills of products to the client to claim warranty.

Note

Civil Engineer will be assigned for the project for inspection and monitoring the quality of work and progress.
Sheds would be constructed at site premises for material storage and Watchman/Labor.
Soil Testing would be done by us before starting the construction.
All the Brand's logos and Some product's images are mentioned just for understanding/reference purpose only. Actual product may look different from the images mentioned in this package.
Floor plans and 3D elevations mentioned in this document is just for reference purpose only, the designs will change as per Site dimensions, Client's requirements etc.
Looking forward to serving you the Quality and Professional Construction service.

Design & Drawings

Floor Plans: Detailed 2D floor plans will be provided.
Note: This Floor plan is just for reference only, Floor plan for each project will be designed as per client’s requirements.
3D elevation view will be provided.
Note: This elevation image is just for reference only, Elevation for each project will be designed as per client’s taste and requirement.
Structural:
Detailed Plinth Beam layouts, Slab shuttering and reinforcements, Columns, Footings, Centre line Drawings and working drawings will be provided.
Plumbing & Electrical Drawings:
Detailed Plumbing and Electrical drawings will be provided.

Sample Design

Structure & Civil

Steel:
ISI standard FE-500/555 TMT Steel will be used.
JSW/TATA or equivalent Brands will be used.
Steel Rods starting from 6mm upto 20mm will be used according to the structural design and requirement.
Cement:
ISI Standard 53 and 43 Grade cement will be used.
ACC Concrete+ or equivalent brand will be used.
53 Grade will be used for Masonry and 43 Grade will be used for Plastering.
Sand -
Certified double water-washed M-Sand will used for Masonry and Plastering-Sand will be used for Plastering.

Blocks/Bricks:
Solid 6-inch and 4-inch concrete blocks will be used.
6-inch blocks for External walls and 4-inch blocks for internal walls.
Note - Wire-cut Red-bricks can be used with EXTRA cost of Rs.100/sqft on the package.
Concrete: ISI Standard M25 Grade Ready Mix Concrete will used for Footing and Slab.
Aggregates - 20mm and 40mm will used.
Waterproofing - Dr.Fixit Water proofing solution will be used.

Kitchen

Kitchen Granite Platform:
Cost of the Granite platform will be up to Rs.180/sqft.
Thickness of the Granite will be up to 40mm.
Granite skirting of 4-inch with chamfering will be provided on the platform.
Ceramic Wall Tiles:
Ceramic Wall Tiles worth upto Rs.65/sqft will be provided.
Height of the Wall tiles will be upto 2 feet above the Granite platform.

Kitchen Sink, Faucets and Accessories:
Stainless Steel (or) Quartz sink of worth up to Rs.8000 will be provided.
Sink Faucet and Accessories worth up to Rs.3000 will be provided.

Bathroom

Sanitaryware and CP fittings:
Sanitaryware and CP fittings will be used of worth upto Rs.50,000.
Includes EWC, Washbasin with Pillarcock, Wallmixer/Diverter, Health Faucet, Overhead shower with Arm and Angle cocks, Concealed stopcock, CP fittings and Accessories.

Ceramic Wall and Floor Tiles:
Ceramic Wall tiles worth upto Rs.65/sqft and Floor tiles worth upto Rs.65/sqft will be provided.
Height of the Wall tiles will be upto 7 feet above the Floor.
Anti-Skid Ceramic Floor tiles will be provided.
CPVC/PVC: Ashirwad/Supreme brand CPVC and PVC will be used in Plumbing.
Bathroom Doors: Premium WPVC Water-Proof Doors will be provided.

Note: Bathrooms will be waterproofed to remain free of leaks. Warranty of 5 years will be provided for Water proofing.

Woodwork

Main door and Frame:
Main door and Frame will be made of Burma Teak wood.
Height and width of the Main door frame will be 7 feet X 3 feet 6 inches.
Thickness of the wood section will be 5 inches X 3 inches.
Door designs will be as per company standards.
Windows:
Premium UPVC 3-Track sliding windows with one-way glass & 12mm MS grills will be provided.
Height and Width of the Windows and Grill design will be as per company standards.

Internal Doors and Frames:
African Teak/ Honne wood will be provided for Internal Door Frames.
Premium Laminated Doors will be provided for Internal Rooms.
Height and width of the Main door frame will be 7 feet X 3 feet.
Thickness of the wood section will be 5 inches X 3 inches.
Door designs will be as per company standards.

Painting

Interior Painting:
2-coats of Birla wall putty will be done.
1-coat of Interior Primer will be provided.
2-coats of Asianpaints Royal emulsion will be provided.

External Painting:
1-coat of Asianpaints Exterior Primer will be done.
2-coats of Asianpaints Ultima for Front Elevation and Apex weatherproof paint for remaining sides will be provided.
Metal and Wood Painting:
2-coats of Asianpaints Enamel painting will be done for Window grills, MS Main Gate.
Same will be applied for Internal wooden Frames if applicable.

Flooring

Living and Dining: Granite of worth up to Rs.160/sqft will be provided.
Staircase:
Granite of worth upto Rs.100/sqft will be provided for staircase steps.
4-inch Skirting with chamfering will be provided.

Bedroom: Granite flooring /Wooden flooring /Branded Vitrified tile flooring of worth upto Rs.130/sqft will be provided.
Balcony and Open areas: Granite or equivalent worth upto Rs.100/sqft will be provided.
Parking: Anti-skid Parking tiles of worth upto Rs.65/sqft will be provided.
Elevation Cladding:
Front Elevation Cladding will be provided.
Cost of cladding will be upto Rs.90/sqft.
Cladding area will be upto 5% of the total built-up area.

Note: Balconies will be waterproofed to remain free of leaks. Warranty of 5 years will be provided for Water proofing.

Electrical

Wires:  Havells/Polycab or equivalent brands Fire-proof wires will be provided.
Switches and Boards: Havells/Legrand or equivalent Switches and Panel Boards will be provided.
Note: Electric fixing and fixtures like Fans, Bulbs, Motor, Meters, Meter Box etc., are not included in the package. It will be of additional cost.

Overhead Tank

ISI standard multi-layered Water Tank will be provided.
Water tank capacity starts from 1000 liters and the capacity depends on the total built-up area.
Underground Sump/Tank:
Underground Sump will be of 8” Solid concrete blocks with waterproof plastering.
Sump tank capacity starts from 5000 liters and the capacity depends on the total built-up area.

Gate and Railings

Main Gate:
MS gates with Modren designs will be provided.
16-gauge round/box pipes will be used.
Staircase and Balcony Railings:
304-grade & 16-gauge Jindal brand SS railing with standard designs will be provided.
Toughened clear glass will be added to SS Railings for Modern look.

Compound wall and Parapet wall

Compound wall:
Compound wall of height 4 feet will be provided.
4-inch Solid concrete blocks & both side plastering and painting will be done.
Parapet wall:
Standard Parapet wall of height 3’6” feet will be provided.
4-inch Solid concrete blocks & both side plastering and painting will be done.

Add-ons

Anti-Termite treatment - Anti-Termite treatment will be done.
Solar provision - Solar provision will be provided.
CCTV - CCTV provision for 4-points will be provided.
Inverter provision - Inverter Provision will be provided.
Texture Painting - Texture painting for Front Elevation will be provided (As per Company Standards).
Elevation Cladding - Elevation cladding will be provided as mentioned in the Flooring section.
Domestic Gas line - Jindal brand Gas pipeline provision will be provided for all the Kitchens.
False ceiling - False ceiling will be provided for Living room up to Rs.60/sqft.

Exclusions from the Package

Interiors -
Interiors are not included in the package.
Temporary Power -
Client must provide Temporary power for the construction.
Temporary power renewal should be done by Client every month until the Construction of project is completed.
Water for Construction of the project - Required amount of Water for construction of the project should be provided by the Client.
Government approvals -
Getting Approvals from the Government is excluded from the package.
Client must get all the Government approvals for the project.

Electrical/BESCOM -
Electrical Meters and Meter Box are not included in the package.
BESCOM charges are NOT included in the package.
Road cutting - Road cutting chares for BESCOM and BWSSB are NOT included in the package.
Breaking/drilling Rock - Rock breaking or drilling expenses will born by Client.

Builhood Pricing

Main areas: Living, Kitchen, Bedrooms, Bathrooms and Staircase will be charged at Rs.1880/sqft.
Parking and Open areas:
Parking area will be charged at 75% of Rs.1880/sqft.
Utility, Balcony and common areas will be charge at 75% of Rs.1880/sqft.
Other areas : Headroom and Tank room will be charged at 85% of Rs.1880/sqft.
Note : Standard height of Headroom is 8-foot and Tank room is 6-foot.
Note: GST [CGST + SGST] is 18% [9% + 9%]

Incl GST* indicates the following...

• CGST 9% will be borne by Company.

• SGST 9% shall be borne by Customer.

Warranty

Warranty of 5 years will be provided for the Construction.
Warranty starts from the date of Handing over the Project to the Client.
Warranty for all the Products can be availed directly from the Manufacturer of the product.
We will be providing all the required Bills of products to the client to claim warranty.

Note

Civil Engineer will be assigned for the project for inspection and monitoring the quality of work and progress.
Sheds would be constructed at site premises for material storage and Watchman/Labor.
Soil Testing would be done by us before starting the construction.
All the Brand's logos and Some product's images are mentioned just for understanding purpose only. Actual product may look different from the images mentioned in this package.
 Floor plans and 3D elevations mentioned in this document is just for reference purpose only, the designs will change as per Site dimensions, Client's requirements etc.
Looking forward to serving you the Quality and Professional Construction service.
